GER/T

Description:

|Material: PTFE + BRONZE + OR-NBR

|Pressure: = 600 bar

|Speed: = 15 m/s

|Temperature: - 35°C + 130°C with OR in NBR

Category: Piston Seals, Subcategory

Product Description

Description:

|Material: PTFE + BRONZE + OR-NBR

|Pressure: = 600 bar

|Speed: = 15 m/s

|Temperature: - 35°C + 130°C with OR in NBR

Additional information

Name Size Materials Speed Stock
GER/T 0250 D.025x017,5x3,2 LEGGERO 17.5-25-3.2 Ptfe/bronzo/nbr 15
GER/T 0350 D.035x024x4,2 24-35-4.2 Ptfe/bronzo/nbr 15
GER/T 0400/1 D.040x029,0x4,2 29-40-4.2 Ptfe/bronzo/nbr 15
GER/T 0400 D.040x032,5x3,2 LEGGERO 32.5-40-3.2 Ptfe/bronzo/nbr 15
GER/T 0500 D.050x034,5x6,3 34.5-50-6.3 Ptfe/bronzo/nbr 15
GER/T 0450 D.045x037,5x3,2 OR-3143 37.5-45-3.2 Ptfe/bronzo/nbr 15
GER/T 0500/1 D.050x039,0x4,2 VIT OR4150 39-50-4.2 Ptfe/bronzo/nbr 15
GER/T 0550 D.055x044,0x4,2 44-55-4.2 Ptfe/bronzo/nbr 15
GER/T 0600 OR-4187 D.060x049,0x4,2 49-60-4.2 Ptfe/bronzo/nbr 15
GER/T 0650 D.065x054,0x4,2 54-65-4.2 Ptfe/bronzo/nbr 15
GER/T 0700/1 D.070x054,5x6,3 OR 4225 54.5-70-6.3 Ptfe/bronzo/nbr 15
GER/T 0650/L OR-3225 D.065x057,5x3,2 57.5-65-3.2 Ptfe/bronzo/nbr 15
GER/T 0700 D.070x059x4,2 OR-228 59-70-4.2 Ptfe/bronzo/nbr 15
GER/T 0750 D.075x064,0x4,2 OR-4250 64-75-4.2 Ptfe/bronzo/nbr 15
GER/T 0900/1 D.090x069,0x8,1 PESANTE 69-90-8.1 Ptfe/bronzo/nbr 15
GER/T 0950 D.095x074x8,1 PESANTE 74-95-8.1 Ptfe/bronzo/nbr 15
GER/T 1000 D.100x079,0x8,1 PESANTE 79-100-8.1 Ptfe/bronzo/nbr 15
GER/T 1000/1OR.6325 D.100x084,5x6,3 84.5-100-6.3 Ptfe/bronzo/nbr 15
GER/T 1100 D.110x089,0x8,1 PESANTE 89-110-8.1 Ptfe/bronzo/nbr 15
GER/T 1200/1 D.120x099x8,1 PESANTE 99-120-8.1 Ptfe/bronzo/nbr 15
GER/T 1200 D.120x104,5x6,3 104.5-120-6.3 Ptfe/bronzo/nbr 15
GER/T 1300 D.130x109x8,1 OR- 109-130-8.1 Ptfe/bronzo/nbr 15
GER/T 1400 D.140x119x8,1 OR-8462 119-140-8.1 Ptfe/bronzo/nbr 15
GER/T/L 1350 D.135x119,5x6,3 LEGGERO 119.5-135-6.3 Ptfe/bronzo/nbr 15
GER/T 1600 D.160x139,0x8,1 139-160-8.1 Ptfe/bronzo/nbr 15
GER/T 1650 D.165x144,0x8,1-OR-8550 144-165-8.1 Ptfe/bronzo/nbr 15
GER/T/L 1600 D.160x144,5x6,3 LEGGERO 144.5-160-6.3 Ptfe/bronzo/nbr 15
GER/T 1800 D.180x159,0x8,1 159-180-8.1 Ptfe/bronzo/nbr 15
GER/T 1850 D.185x164,0x8,1 164-185-8.1 Ptfe/bronzo/nbr 15
GER/T 2000 D.200x179,0x8,1 179-200-8.1 Ptfe/bronzo/nbr 15
GER/T/L 2000 D.200x184,5x6,3 184.5-200-6.3 Ptfe/bronzo/nbr 15
GER/T 2350 D.235x214x8,1 OR.8825 214-235-8.1 Ptfe/bronzo/nbr 15
GER/T 2500 D.250x229,5x8,1 229.5-250-8.1 Ptfe/bronzo/nbr 15
GER/T 3000 OR-81050 D.300x275,5x8,1 275.5-300-8.1 Ptfe/bronzo/nbr 15
GER/T 3000/1 OR.81100 D.300x279x8,1 279-300-8.1 Ptfe/bronzo/nbr 15
GER/T 3200 OR-81150 D.320x299x8,1 299-320-8.1 Ptfe/bronzo/nbr 15
GER/T 3300 D.330x305x8,1 OR.81200 305-330-8.1 Ptfe/bronzo/nbr 15
GER/T 3550 D.355x330,5x8,1 OR.81300 330.5-355-8.1 Ptfe/bronzo/nbr 15
GER/T 3600 D.360x335,5x8,1 OR.81300 335.5-360-8.1 Ptfe/bronzo/nbr 15
GER/T 4000 OR 81450 D.400x375,50x8,1 375.5-400-8.1 Ptfe/bronzo/nbr 15
GER/T 4500 D.450x425,50x8,1 425.5-450-8.1 Ptfe/bronzo/nbr 15
GER/T 4600 D.460x432x9,5 432-460-9.5 Ptfe/bronzo/nbr 15
GER/T 4800 D.480x455,50x8,1 455.5-480-8.1 Ptfe/bronzo/nbr 15
GER/T 5000 D.500x475,50x8,1 475.5-500-8.1 Ptfe/bronzo/nbr 15
GER/T 5550 D.555x530,50x8,1 530.5-555-8.1 Ptfe/bronzo/nbr 15
GER/T 6400 D.640x615,5x8,1 615.5-640-8.1 Ptfe/bronzo/nbr 15
GER/T 6600 D.660x635,5x8,1 OR-82500 635.5-660-8.1 Ptfe/bronzo/nbr 15
GER/T 6700 D.670x642x9,5 642-670-9.5 Ptfe/bronzo/nbr 15
GER/T 7000 D.700x672x9,5 672-700-9.5 Ptfe/bronzo/nbr 15
GER/T 7800 D.780x752x9,5 752-780-9.5 Ptfe/bronzo/nbr 15
GER/T 8050 D.805x777x9,5 777-805-9.5 Ptfe/bronzo/nbr 15
GER/T 8400 D.840x812x9,5 812-840-9.5 Ptfe/bronzo/nbr 15
GER/T 9450 D.945x917x9,5 917-945-9.5 Ptfe/bronzo/nbr 15
GER/T 10500/L D.1050x1022x9,6 1022-1050-9.6 Ptfe/bronzo/nbr 15
GER/T 10700 D.1070x1032x13,8 1032-1070-13.8 Ptfe/bronzo/nbr 15
GER/T 11000 D.1100x1062x13,8 1062-1100-13.8 Ptfe/bronzo/nbr 15
GER/T 11500 D.1150x1112x13,8 1112-1150-13.8 Ptfe/bronzo/nbr 15
GER/T 12810 D.1281x1243x13,8 1243-1281-13.8 Ptfe/bronzo/nbr 15
