K83 K84

|Description: |Material: PU. |Temperature: - 35°C + 100°C |Pressure: = 600 bar

Category: O-ring (OR), Subcategory

Product Description

|Description: |Material: PU. |Temperature: - 35°C + 100°C |Pressure: = 600 bar

Additional information

Name Size Materials Speed Stock
K84-014 D.014x011x2,6 11-14-2.6 Pu 12
K83-012 D.012x016,5x3,2 12-16.5-3.2 Pu 12
K84-016 D.016x013x2,6 13-16-2.6 Pu 12
K84-017 D.017x014x3,5 14-17-3.5 Pu 12
K83-016 D.016x020x4,8 16-20-4.8 Pu 12
K84-019 D.019x016x3,5 16-19-3.5 Pu 12
PU82 24359080 D.016x021x4,65/5 16-21-4.65 Pu 12
K84-020 D.020x016,2x3,2 16.2-20-3.2 Pu 12
K84-023 D.023x018,8x5 18.8-23-5 Pu 12
K83-020 D.020x024x4,8 20-24-4.8 Pu 12
K83-020/2 D.020x025x5,3 20-25-5.3 Pu 12
K84-024 D.024x020x3,3 20-24-3.3 Pu 12
K84-025 D.025,4x020,15x3,85 20.15-25.4-3.85 Pu 12
K83-020/1 D.020,5x025x4 20.5-25-4 Pu 12
K84-026 D.026x021,4x3,9 21.4-26-3.9 Pu 12
K83-025 D.025x029,2x5 25-29.2-5 Pu 12
K84-030 D.030x025,4x3,9 25.4-30-3.9 Pu 12
K84-032 D.032x027,4x3,9 27.4-32-3.9 Pu 12
K84-032/1 D.032x028x3,4 28-32-3.4 Pu 12
K84-033 D.033x029,2x2,7 29.2-33-2.7 Pu 12
K83-030 D.030x034x4,8 30-34-4.8 Pu 12
K84-035 D.035x030,4x3,9 30.4-35-3.9 Pu 12
COVER SEAL PU83 24367566 D.040x032x2,8 32-40-2.8 Pu 12
K84-040/1 D.040x032,8x3,4 32.8-40-3.4 Pu 12
K84-040 D.040x033,5x4,8 33.5-40-4.8 Pu 12
COVER SEAL PU83 49065681 D.040x035x5,4 35-40-5.4 Pu 12
K83-035 D.035x039,5x4,5 35-39.5-4.5 Pu 12
K84-038 D.038x035x3 35-38-3 Pu 12
COVER SEAL PU82 24250882 D.041x036x4,9 36-41-4.9 Pu 12
K84-040/2 D.040x036x3,4 36-40-3.4 Pu 12
K84-041 D.041x037x3,4 37-41-3.4 Pu 12
K84-042 D.042,5x037,5x3,7 37.5-42.5-3.7 Pu 12
K84-045 D.045x039,5x4,5 39.5-45-4.5 Pu 12
K83-040 D.040x046x3 40-46-3 Pu 12
COVER SEAL PU83 49065618 D.045x040x5,4 40-45-5.4 Pu 12
COVER SEAL PU83 40422462 D.050x042x5 42-50-5 Pu 12
K83-042 D.042x050x6,4 42-50-6.4 Pu 12
COVER SEAL PU83 49055450 D.050x044x5,2 44-50-5.2 Pu 12
K84-050/1 D.050x044,4x4,8 44.4-50-4.8 Pu 12
K84-050 D.050x044,4x6,2 44.4-50-6.2 Pu 12
COVER SEAL PU82 49065621 D.049x045x5,4 45-49-5.4 Pu 12
K84-050/2 D.050x045,40x3,9 45.4-50-3.9 Pu 12
K84-051 D.051x046,4x3,9 46.4-51-3.9 Pu 12
K84-052 D.052,5x048x3,6 48-52.5-3.6 Pu 12
COVER SEAL PU82 49065620 D.054x050x5,4 50-54-5.4 Pu 12
K83-050 D.050x058x6,4 50-58-6.4 Pu 12
K84-056 D.056x051,4x3,9 51.4-56-3.9 Pu 12
COVER SEAL PU83 40422459 D.060x052x5 52-60-5 Pu 12
K84-057 D.057x052x4 52-57-4 Pu 12
K84-060 D.060x052,2x5,8 52.2-60-5.8 Pu 12
K84-060/1 D.060x053,7x5,2 53.7-60-5.2 Pu 12
COVER SEAL PU83 24380802 D.060x054x5,5 54-60-5.5 Pu 12
COVER SEAL PU83 49001027 D.060x054x5,3 54-60-5.3 Pu 12
K84-060/2 D.060x054,6x6,2 54.6-60-6.2 Pu 12
COVER SEAL PU82 49065619 D.059x055x5,4 55-59-5.4 Pu 12
K83-055 D.055x060,4x6,2 55-60.4-6.2 Pu 12
K84-061 D.061x055,5x4,5 55.5-61-4.5 Pu 12
COVER SEAL PU83 40422460 D.065x057x5 57-65-5 Pu 12
K84-065 D.065x057,2x5,8 57.2-65-5.8 Pu 12
K84-063 D.063x057,4x6,2 57.4-63-6.2 Pu 12
K84-063/1 D.063x057,50x4,5 57.5-63-4.5 Pu 12
K84-064/1 D.064x057,9x4,85 57.9-64-4.85 Pu 12
K84-064 D.064x058,5x4,5 58.5-64-4.5 Pu 12
K84-065/1 D.065x059,4x4,6 59.4-65-4.6 Pu 12
COVER SEAL PU82 40422499 D.065x060x4,4 60-65-4.4 Pu 12
K83-060 D.060x065,5x5,2 60-65.5-5.2 Pu 12
K84-066 D.066x060,5x4,5 60.5-66-4.5 Pu 12
COVER SEAL PU83 532201 D.070x064,4x2,8/5,2 64.4-70-2.8 Pu 12
K84-070 D.070x064,40x6,2 64.4-70-6.2 Pu 12
K84-070/1 D.070x064,50x4,5 64.5-70-4.5 Pu 12
K84-071/1 D.071x064,7x4,85 64.7-71-4.85 Pu 12
K83-065 D.065x070,6x6,2 65-70.6-6.2 Pu 12
K84-071 D.071x065,5x4,5 65.5-71-4.5 Pu 12
COVER SEAL PU83 40422519 D.075x069x5,5 69-75-5.5 Pu 12
K84-075 D.075x069,6x6,5 69.6-75-6.5 Pu 12
COVER SEAL PU82 24250879 D.076x070x4,9 70-76-4.9 Pu 12
K83-070 D.070x075,6x6,2 70-75.6-6.2 Pu 12
K83-070/1 D.070x077x5,5 70-77-5.5 Pu 12
K84-076 D.076x070,5x4,50 70.5-76-4.5 Pu 12
COVER SEAL PU83 40422408 D.081x073,2x4,6 73.2-81-4.6 Pu 12
K84-081 D.081x073,2x5 73.2-81-5 Pu 12
K84-080/1 D.080x074,50x4,5 74.5-80-4.5 Pu 12
K84-080 D.080x074,6x6,5 74.6-80-6.5 Pu 12
K83-075 D.075x082x5,5 75-82-5.5 Pu 12
K84-080/2 D.080,5x075x4,5 75-80.5-4.5 Pu 12
K84-081/1 D.081x075,5x4,5 75.5-81-4.5 Pu 12
COVER SEAL PU83 24269861 D.085x080x4,2 80-85-4.2 Pu 12
COVER SEAL PU83 40422495 D.090x080x6,7 80-90-6.7 Pu 12
K83-080 D.080x090x10,5 80-90-10.5 Pu 12
K84-090 D.090x080,1x7,8 80.1-90-7.8 Pu 12
K84-085 D.085x080,8x5 80.8-85-5 Pu 12
K84-090/2 D.090,5x081,5x7 81.5-90.5-7 Pu 12
K84-088 D.088x083,4x4 83.4-88-4 Pu 12
K84-090/1 D.090x084,50x4,5 84.5-90-4.5 Pu 12
K84-091/2 D.091x084,8x5,2 84.8-91-5.2 Pu 12
K84-091 D.091x085,6x4,5 85.6-91-4.5 Pu 12
K84-095/1 D.095x086,4x9 86.4-95-9 Pu 12
COVER SEAL PU83 24293063 D.095x087x5 87-95-5 Pu 12
K84-095 D.095,5x087,7x5 87.7-95.5-5.5 Pu 12
K84-095/2 D.095,5x087,7x5 87.7-95.5-5 Pu 12
K84-095/3 D.095x088,4x7 88.4-95-7 Pu 12
COVER SEAL PU83 40422493 D.100x090x6,7 90-100-6.7 Pu 12
K83-090 D.090x110x12,3 90-110-12.3 Pu 12
K83-090/1 D.090x097x5,5 90-97-5.5 Pu 12
K84-100 D.100x090x7,8 90-100-7.8 Pu 12
K84-100/5 D.100x090x5 90-100-5 Pu 12
K84-100/4 D.100x090,2x9,4 90.2-100-9.4 Pu 12
K84-100/3 D.100x090,3x9 90.3-100-9 Pu 12
K84-100/1 D.100x091,4x9 91.4-100-9 Pu 12
K84-100/7 D.100,5x091,5x7 91.5-100.5-7 Pu 12
K83-092 D.092x097x2,9 92-97-2.9 Pu 12
K84-101/1 D.101x093x7,4 93-101-7.4 Pu 12
K84-100/2 D.100x093,70x3,2 93.7-100-3.2 Pu 12
K84-101 D.101x094,7x5,2 94.7-101-5.2 Pu 12
COVER SEAL PU83 40422492 D.105x095x6,7 95-105-6.7 Pu 12
K84-105 D.105x095,1x6,7/7,8 95-105-6.7 Pu 12
K83-100 D.100x105,6x6,2 100-105.6-6.2 Pu 12
K84-110 D.110x101,4x9 101.4-110-9 Pu 12
K84-110/1 D.110x103,70x5,2 103.7-110-5.2 Pu 12
COVER SEAL PU83 40422490 D.115x105x6,7 105-115-6.7 Pu 12
K83-105 D.105x112,8x5,8 105-112.8-5.8 Pu 12
K84-115/1 D.115x105x5 105-115-5 Pu 12
K83-107 D.107x112,4x6,2 107-112.4-6.2 Pu 12
K84-115 D.115x108,8x5,9 108.8-115-5.9 Pu 12
K83-109 D.109x114,6x6,2 109-114.6-6.2 Pu 12
K84-116 D.116x109,70x5,2 109.7-116-5.2 Pu 12
K83-110 D.110x117x4,7 110-117-4.7 Pu 12
K84-120/1 D.120x110,8x8 110.8-120-8 Pu 12
K84-120 D.120x112x6,5 112-120-6.5 Pu 12
K84-124 D.124x114x7,3 114-124-7.3 Pu 12
COVER SEAL PU83 40422491 D.125x115x6,7 115-125-6.7 Pu 12
COVER SEAL PU83 49001025 D.122x115x5,7 115-122-5.7 Pu 12
K83-115 D.115x123,6x9 115-123.6-9 Pu 12
K84-121 D.121x115,5x4,5 115.5-121-4.5 Pu 12
K84-125 D.125x116,4x9 116.4-125-9 Pu 12
COVER SEAL PU82 24245387 D.117x123,1x4,6/5,9 117-123.1-4.9 Pu 12
K83-117 D.117x122,6x6,2 117-122.6-6.2 Pu 12
K84-125/1 D.125x118,70x5,2 118.7-125-5.2 Pu 12
K83-120/1 D.120x125x4,2 120-125-4.2 Pu 12
COVER SEAL PU83 24311962 D.130x120x4,2 120-130-4.2 Pu 12
K83-120 D.120x140x12,3 120-140-12.3 Pu 12
K84-130/1 D.130x120,6x7,9 120.6-130-7.9 Pu 12
K83-122 D.122x127,6x6,2 122-127.6-6.2 Pu 12
K84-128 D.128x122,6x4,5 122.6-128-4.5 Pu 12
K84-130 D.130x123,70x5,2 123.7-130-5.2 Pu 12
K84-134 D.134x124,6x7,9 124.6-134-7.9 Pu 12
K84-135/2 D.135x125x7,3 125-135-7.3 Pu 12
K84-136 D.136x125,8x9,3 125.8-136-9.3 Pu 12
K84-135/1 D.135x126x9,1 126-135-9.1 Pu 12
K84-135 D.135x128x5,5 128-135-5.5 Pu 12
COVER SEAL PU83 24362518 D.140x130x6,6 130-140-6.6 Pu 12
K84-140/4 D.140x130,8x9 130.8-140-9 Pu 12
K84-140/1 D.140x133,70x5,2 133.7-140-5.2 Pu 12
COVER SEAL PU83 40422341 D.140x134,1x4,9/5,9 134.1-140-4.9 Pu 12
K84-140 D.140x134,1x5,9 134.1-140-5.9 Pu 12
K83-136 D.136x142,5x6,1 136-142.5-6.1 Pu 12
K84-145 D.145x139,1x5,9 139.1-145-5.9 Pu 12
COVER SEAL PU83 40422496 D.150x140,4x6,6/7,3 140.4-150-6.6 Pu 12
K84-150/2 D.150x140,7x9,5 140.7-150-9.5 Pu 12
COVER SEAL PU83 24348854 D.150x141x8 141-150-8 Pu 12
K84-150 D.150x141,9x9,2 141.9-150-9.2 Pu 12
K84-150/1 D.150x143,70x5,2 143.7-150-5.2 Pu 12
K83-145 D.145x150x4,2 145-150-4.2 Pu 12
K83-147 D.147x152,6x6,2 147-152.6-6.2 Pu 12
K84-156 D.156x148,8x4,5 148.8-156-4.5 Pu 12
K84-160/2 D.160x149,4x8,6 149.4-160-8.6 Pu 12
K83-149 D.149,8x156,3x5,2 149.8-156.3-5.2 Pu 12
K84-160 D.160x150x8,4 150-160-8.4 Pu 12
K84-160/1 D.160x153,7x5,2 153.7-160-5.2 Pu 12
K84-162 D.162x154x8,2 154-162-8.2 Pu 12
K84-164 D.164x154x8 154-164-8 Pu 12
K84-165 D.165x155x8,4 155-165-8.4 Pu 12
K84-165/1 D.165x158,6x6,1 158.6-165-6.1 Pu 12
COVER SEAL PU83 24250883 D.165x159x4,9 159-165-4.9 Pu 12
K84-170 D.170x160x8,4 160-170-8.4 Pu 12
K83-162 D.162x167,6x6,2 162-167.6-6.2 Pu 12
K84-175 D.175x165x8,4 165-175-8.4 Pu 12
K84-180 D.180x170x8,4 170-180-8.4 Pu 12
K83-170 D.170,8x177,4x5,2 170.8-177.4-5.2 Pu 12
K84-180/1 D.180x171,40x6,9 171.4-180-6.9 Pu 12
K84-183 D.183x175x8,5 175-183-8.5 Pu 12
K84-185 D.185x175x8,4 175-185-8.4 Pu 12
K84-186 D.186x176x8 176-186-8 Pu 12
K84-190 D.190x180x8,4 180-190-8.4 Pu 12
COVER SEAL PU83 24250878 D.192x185x4,9 185-192-4.9 Pu 12
K84-195 D.195x185x8,4 185-195-8.4 Pu 12
K84-200/1 D.200x190x8,4 190-200-8.4 Pu 12
K84-200/3 D.200x191x9,3 191-200-9.3 Pu 12
K84-200 D.200x191,4x9 191.4-200-9 Pu 12
K84-200/2 D.200x191,4x6,9 191.4-200-6.9 Pu 12
COVER SEAL PU83 24250880 D.200x193x4,9 193-200-4.9 Pu 12
K84-205 D.205x195x8,4 195-205-8.4 Pu 12
K84-210 D.210x200x8,4 200-210-8.4 Pu 12
K84-215 D.215x205x8,4 205-215-8.4 Pu 12
K84-220 D.220x210x8,4 210-220-8.4 Pu 12
K83-212 D.212x236x12 212-236-12 Pu 12
K84-222 D.222x214x8 214-222-8 Pu 12
K84-225 D.225x215x8,4 215-225-8.4 Pu 12
K84-230 D.230x220x8,4 220-230-8.4 Pu 12
K84-230/1 D.230x222x8,5 222-230-8.5 Pu 12
K84-235 D.235x225x8,4 225-235-8.4 Pu 12
K84-240 D.240x231,4x9 231.4-240-9 Pu 12
COVER SEAL PU83 24245390 D.242x236x4,9 236-242-4.9 Pu 12
K84-250 D.250x238,4x12,3 238.4-250-12.3 Pu 12
K84-255 D.255x240x12,9 240-255-12.9 Pu 12
K84-252 D.252x242x8,4 242-252-8.4 Pu 12
K84-286 D.286x263x12 263-286-12 Pu 12
K84-275 D.275x263,4x12,30 263.4-275-12.3 Pu 12
K84-280 D.280x271,4x9 271.4-280-9 Pu 12
COVER SEAL PU83 24250877 D.288x282x4,9 282-288-4.9 Pu 12
K84-300 D.300x283x16,30 283-300-16.3 Pu 12
K84-305 D.305x290x12,9 290-305-12.9 Pu 12
K84-307 D.307x292x12,9 292-307-12.9 Pu 12
K84-320 D.320x308,4x12,3 308.4-320-12.3 Pu 12
K84-350 D.350x333x16,3 333-350-16.3 Pu 12
K84-355 D.355x340x12,9 340-355-12.9 Pu 12
