TDE

|Description: |Material: Nbr / Rubbercloth / Pom |Pressure: = 500 bar |Speed: = 0,5 m/s |Temperature: - 35°C + 110°C with Nbr / Rubbercloth / Pom |Temperature: - 50°C + 200°C with FKM /VITON+ Rubbercloth

Category: Piston Seals, Subcategory

Product Description

|Description: |Material: Nbr / Rubbercloth / Pom |Pressure: = 500 bar |Speed: = 0,5 m/s |Temperature: - 35°C + 110°C with Nbr / Rubbercloth / Pom |Temperature: - 50°C + 200°C with FKM /VITON+ Rubbercloth

Additional information

Name Size Materials Speed Stock
TDE 098047 D.025x012x012,40 12-25-12.4 Nbr/gommatela/pom 0.5
TDE 118066 D.030x017x015,40 17-30-15.4 Nbr/gommatela/pom 0.5
DPC 118066 D.030x017x15,40 17-30-15.4 Nbr/gommatela/pom 0.5
D11W 125074 D.032,00x019,00x15,40 TDE 19-32-15.4 Nbr/gommatela/pom 0.5
TDE 137086 D.035x022x015,40 22-35-15.4 Nbr/gommatela/pom 0.5
D11W 137086 D.035,00x022,00x15,40 22-35-15.4 Nbr/gommatela/pom 0.5
DPC 137086 D.035x022x15,40 22-35-15.4 Nbr/gommatela/pom 0.5
TDE 157094 D.040x024x018,40 24-40-18.4 Nbr/gommatela/pom 0.5
D11W 157094 D.040,00x024,00x18,40 24-40-18.4 Nbr/gommatela/pom 0.5
DPC 157094 D.040x024x18,40 24-40-18.4 Nbr/gommatela/pom 0.5
VITON TDE 157094 D.040x024x18,40 24-40-18.4 Viton/gommatela/pom 0.5
TDE 177114 D.045x029x018,40 29-45-18.4 Nbr/gommatela/pom 0.5
D11W 177114 D.045,00x029,00x18,40 29-45-18.4 Nbr/gommatela/pom 0.5
DPC 177114 D.045x029x18,40 29-45-18.4 Nbr/gommatela/pom 0.5
TDE 196118 D.050x030x025,40 30-50-25.4 Nbr/gommatela/pom 0.5
D11W 196118 D.050,00x030,00x25,40 30-50-25.4 Nbr/gommatela/pom 0.5
TDE 196133 D.050x034x018,40 34-50-18.4 Nbr/gommatela/pom 0.5
VITON TDE 196133 D.050x034x18,40 34-50-18.4 Viton/gommatela/pom 0.5
DPC 196133 D.050x034x18,40 34-50-18.4 Nbr/gommatela/pom 0.5
D11W 200137 D.050,80x034,92x19,45 34.92-50.8-19.45 Nbr/gommatela/pom 0.5
VITON TDE 216153 D.055x038x18,40 38-55-18.4 Viton/gommatela/pom 0.5
D11W 212150 D.053,97x038,10x19,45 TDE 38.1-53.97-19.45 Nbr/gommatela/pom 0.5
TDE 216153 D.055x039x018,40 39-55-18.4 Nbr/gommatela/pom 0.5
DPC 216153 D.055x039x18,40 39-55-18.4 Nbr/gommatela/pom 0.5
IDDW 225162 W D.057,15x041,27x19,45 41.27-57.15-19.45 Nbr/gommatela/pom 0.5
DPC 236173 D.060x044x18,40 44-60-18.4 Nbr/gommatela/pom 0.5
TDE 236173/1 D.060x044x018,50 44-60-18.5 Nbr/gommatela/pom 0.5
VITON TDE 236173/1 D.060x044x18,50 44-60-18.5 Viton/gommatela/pom 0.5
TDE 236173/2 D.060x044x020,00 44-60-20 Nbr/gommatela/pom 0.5
D11W 237175 D.060,32x044,45x19,45 44.45-60.32-19.45 Nbr/gommatela/pom 0.5
TDE 248185 D.063x047x019,40 47-63-19.4 Nbr/gommatela/pom 0.5
D11W 248185 D.063x047x19,40 47-63-19.4 Nbr/gommatela/pom 0.5
VITON TDE 248185 D.063x047x19,40 47-63-19.4 Viton/gommatela/pom 0.5
D11W / DB 250187 D.063,50x047,62x19,45 47.62-63.5-19.45 Nbr/gommatela/pom 0.5
TDE 255196 D.065x050x018,40 50-65-18.4 Nbr/gommatela/pom 0.5
D11W 255196 D.065,00x050,00x18,40 50-65-18.4 Nbr/gommatela/pom 0.5
DPC 255196 D.065x050x18,40 50-65-18.4 Nbr/gommatela/pom 0.5
TDE 275196 D.070x050x022,40 50-70-22.4 Nbr/gommatela/pom 0.5
D11W 275196 D.070,00x050,00x22,40 50-70-22.4 Nbr/gommatela/pom 0.5
DPC 275196 D.070x050x22,40 50-70-22.4 Nbr/gommatela/pom 0.5
VITON TDE 275196 D.070x050x22,40 50-70-22.4 Viton/gommatela/pom 0.5
D11W 275200 D.069,85x050,80x24,21 50.8-69.85-24.21 Nbr/gommatela/pom 0.5
TDE 295216 D.075x055x022,40 55-75-22.4 Nbr/gommatela/pom 0.5
ANELLO TDE 295216 BIANCO 55-75-22.4 Pom 0.5
DPC 295216 D.075x055x22,40 55-75-22.4 Nbr/gommatela/pom 0.5
TDE 295220 D.075x056x024,40 56-75-24.4 Nbr/gommatela/pom 0.5
D11W 295220 D.075x056x24,40 56-75-24.4 Nbr/gommatela/pom 0.5
VITON TDE 295220 D.075x056x24,40 56-75-24.4 Viton/gommatela/pom 0.5
TDE 300225 D.076,20x057,15x22,4 57.15-76.2-22.4 Nbr/gommatela/pom 0.5
D11W 300225 D.076,20x057,15x24,21 57.15-76.2-24.21 Nbr/gommatela/pom 0.5
TDE 314236 D.080x060x022,40 60-80-22.4 Nbr/gommatela/pom 0.5
DB 314236 D.080x060x22,40 60-80-22.4 Nbr/gommatela/pom 0.5
VITON TDE 314236 D.080x060x22,40 60-80-22.4 Viton/gommatela/pom 0.5
TDE 326248 D.083x063x022,40 63-83-22.4 Nbr/gommatela/pom 0.5
D11W 325250 D.082,55x063,50x24,21 63.5-82.55-24.21 Nbr/gommatela/pom 0.5
TDE 334255 D.085x065x022,40 65-85-22.4 Nbr/gommatela/pom 0.5
D11W 334255 D.085,00x065,00x22,40 65-85-22.4 Nbr/gommatela/pom 0.5
DPC 334255 D.085x065x22,40 65-85-22.4 Nbr/gommatela/pom 0.5
VITON TDE 334255 D.085x065x22,40 65-85-22.4 Viton/gommatela/pom 0.5
VIT IDDW 350275-W D.088,90x069,85x24,21 69.85-88.9-24.21 Nbr/gommatela/pom 0.5
TDE 354275 D.090x070x022,40 70-90-22.4 Nbr/gommatela/pom 0.5
DPC 354275 D.090x070x22,40 70-90-22.4 Nbr/gommatela/pom 0.5
VITON TDE 354275 AN CA. BR D.090x070x22,40 70-90-22.4 Viton/ptfe/bronzo 0.5
VITON TDE 354275 D.090x070x22,40 70-90-22.4 Viton/gommatela/pom 0.5
TDE 354275/1 D.090x070x025,40 70-90-25.4 Nbr/gommatela/pom 0.5
D11W 354275 D.090,00x070,00x25,40 70-90-25.4 Nbr/gommatela/pom 0.5
TDE 374295 D.095x075x022,40 75-95-22.4 Nbr/gommatela/pom 0.5
TDE 393295 D.100x075x022,40 75-100-22.4 Nbr/gommatela/pom 0.5
DPC 374295 D.095x075x22,40 75-95-22.4 Nbr/gommatela/pom 0.5
DPC 393295 D.100x075x22,40 75-100-22.4 Nbr/gommatela/pom 0.5
VITON TDE 393295 D.100x075x022,4 75-100-22.4 Viton/gommatela/pom 0.5
D11W 413314 D.105x080x22,40 80-105-22.4 Nbr/gommatela/pom 0.5
TDE 413314 D.105x080x022,40 80-105-22.4 Nbr/gommatela/pom 0.5
TDE 393314 D.100x080x025,40 80-100-25.4 Nbr/gommatela/pom 0.5
VITON TDE 393314 D.100x080x025,40 80-100-25.4 Viton/gommatela/pom 0.5
DPC 393314 D.100x080x25,40 80-100-25.4 Nbr/gommatela/pom 0.5
VITON TDE 393314 AN CAR BRONZO D.100x080x025,4 80-100-25.4 Viton/ptfe/bronzo 0.5
TDE 400325 D.101,60x082,55x24,21 82.55-101.4-24.21 Nbr/gommatela/pom 0.5
IDDW 400325-W D.101,6x082,55x24,21 82.55-101.6-24.21 Nbr/gommatela/pom 0.5
D11W 400325 D.101,67x082,55x24,21 82.55-101.67-24.21 Nbr/gommatela/pom 0.5
VITON TDE 400325 D.101,60x082,55x024,21 82.55-101.6-24.21 Viton/gommatela/pom 0.5
TDE 433334/1 D.110x085x022,40 85-110-22.4 Nbr/gommatela/pom 0.5
10DPC 10585 D.105x085x22,40 85-105-22.4 Nbr/gommatela/pom 0.5
DPC 413334 D.105x085x22,40 85-105-22.4 Nbr/gommatela/pom 0.5
DPC 433334/1 D.110x085x22,40 85-110-22.4 Nbr/gommatela/pom 0.5
D11W 433334 D.110x085x25,40 85-110-25.4 Nbr/gommatela/pom 0.5
TDE 433334 D.110x085x025,40 85-110-25.4 Nbr/gommatela/pom 0.5
VITON TDE 433334 D.110x085x025,40 85-110-25.4 Viton/gommatela/pom 0.5
TDE 450350 D.114,3x088,9x32,1 NS 88.9-114.3-32.1 Nbr/gommatela/pom 0.5
IDDW 450350-W D.114,30x088,90x32,15 88.9-114.3-32.15 Nbr/gommatela/pom 0.5
D11W 450350 D.114,3x088,9x32,15 88.9-114.3-32.15 Nbr/gommatela/pom 0.5
TDE 452354 D.115x090x022,40 90-115-22.4 Nbr/gommatela/pom 0.5
TDE 433354 D.110x090x025,40 90-110-25.4 Nbr/gommatela/pom 0.5
D11W 433354 D.110x090x25,40 90-110-25.4 Nbr/gommatela/pom 0.5
VITON TDE 433354 D.110x090x25,4 90-110-25.4 Viton/gommatela/pom 0.5
D11W 472374 D.120x095x22,4 95-120-22.4 Nbr/gommatela/pom 0.5
TDE 472374 D.120x095x022,40 95-120-22.4 Nbr/gommatela/pom 0.5
VITON TDE 472374 D.120x095x22,4 95-120-22.4 Viton/gommatela/pom 0.5
D11W 475375 D.120,65x095,25x32,15 95.25-120.65-32.15 Nbr/gommatela/pom 0.5
TDE 472393 D.120x100x025,40 100-120-25.4 Nbr/gommatela/pom 0.5
TDE 492393 D.125x100x025,40 100-125-25.4 Nbr/gommatela/pom 0.5
VITON TDE 472393 D.120x100x25,4 100-120-25.4 Viton/gommatela/pom 0.5
VITON TDE 492393 D.125x100x25,4 100-125-25.4 Viton/gommatela/pom 0.5
D11W 492393 D.125x100x25,4 100-125-25.4 Nbr/gommatela/pom 0.5
DPC 472393 D.120x100x25,40 100-120-25.4 Nbr/gommatela/pom 0.5
TDE 492393/1 D.125x100X032,40 100-125-32.4 Nbr/gommatela/pom 0.5
VITON TDE 492393/1 D.125x100x32,4 100-125-32.4 Viton/gommatela/pom 0.5
TDE 500400 D.127x101,60x32,15 101.6-127-32.15 Nbr/gommatela/pom 0.5
TDE 492413 D.125x105x025,40 105-125-25.4 Nbr/gommatela/pom 0.5
TDE 511413 D.130x105x025,40 105-130-25.4 Nbr/gommatela/pom 0.5
D11W 492413 D.125x105x25,4 105-125-25.4 Nbr/gommatela/pom 0.5
DPC 511413 D.130x105x25,40 105-130-25.4 Nbr/gommatela/pom 0.5
VITON TDE 492413 D.125x105x25,40 105-125-25.4 Viton/gommatela/pom 0.5
VITON TDE 511413 D.130x105x25,4 105-130-25.4 Viton/gommatela/pom 0.5
D11W 525425 D.133,35x107,95x32,15 107.95-133.35-32.15 Nbr/gommatela/pom 0.5
TDE 531433 D.135x110x025,40 110-135-25.4 Nbr/gommatela/pom 0.5
D11W 531433 D.135x110x25,4 110-135-25.4 Nbr/gommatela/pom 0.5
D11W 550450 D.139,70x114,30x32,15 114.3-139.7-32.15 Nbr/gommatela/pom 0.5
TDE 551452 D.140x115x025,40 115-140-25.4 Nbr/gommatela/pom 0.5
VITON TDE 551452 D.140x115x25,4 115-140-25.4 Viton/gommatela/pom 0.5
TDE 551472 D.140x120x025,40 120-140-25.4 Nbr/gommatela/pom 0.5
TDE 570472 D.145x120x025,40 120-145-25.4 Nbr/gommatela/pom 0.5
D11W 551472 D.140x120x25,4 120-140-25.4 Nbr/gommatela/pom 0.5
D11W 570472 D.145x120x25,4 120-145-25.4 Nbr/gommatela/pom 0.5
TDE 590472 D.150x120x038,40 120-150-38.4 Nbr/gommatela/pom 0.5
D11W 590472 D.150x120x38,40 120-150-38.4 Nbr/gommatela/pom 0.5
D11W 575475 D.146,05x120,65x32,15 120.65-146.05-32.15 Nbr/gommatela/pom 0.5
TDE 590492 D.150x125x025,40 125-150-25.4 Nbr/gommatela/pom 0.5
VITON TDE 590492 D.150x125x25,4 125-150-25.4 Viton/gommatela/pom 0.5
15D11WE 150125 D.150x125x25,4x6,35 125-150-25.4 Nbr/gommatela/pom 0.5
D11W 590492 D.150,00x125,00x25,40 125-150-25.4 Nbr/gommatela/pom 0.5
DPC 590492 D.150x125x25,40 125-150-25.4 Nbr/gommatela/pom 0.5
10D11W 600500 D.152,4x127x32,15 127-152.4-32.15 Nbr/pom/tpe 0.5
D11W 610511 D.155x130x25,40 130-155-25.4 Nbr/gommatela/pom 0.5
TDE 610511 D.155x130x025,40 130-155-25.4 Nbr/gommatela/pom 0.5
TDE 629511 D.160x130x025,40 130-160-25.4 Nbr/gommatela/pom 0.5
D11W 629511 D.160x130x25,40 130-160-25.4 Nbr/gommatela/pom 0.5
TDE 638511 D.162x130x025,40 130-162-25.4 Nbr/gommatela/pom 0.5
VITON TDE 629511 D.160x130x25,4 130-160-25.4 Viton/gommatela/pom 0.5
D11W 650550 D.165,10x139,70x32,15 139.7-165.1-32.15 Nbr/gommatela/pom 0.5
TDE 669551 D.170x140x025,40 140-170-25.4 Nbr/gommatela/pom 0.5
D11W 669551 D.170,00x140,00x25,40 140-170-25.4 Nbr/gommatela/pom 0.5
D11W 688570 D.175,00x145,00x35,40 145-175-35.4 Nbr/gommatela/pom 0.5
TDE 708590 D.180x150x035,40 150-180-35.4 Nbr/gommatela/pom 0.5
D11W 708590 D.180x150x35,40 150-180-35.4 Nbr/gommatela/pom 0.5
TDE/SP 708590 D.180x150x35,4 BRIT 150-180-35.4 Brit/gommatela/pom 0.5
VITON TDE 708590 AN CA.BR.D.180x150x35,4 150-180-35.4 Viton/ptfe/bronzo 0.5
VITON TDE 708590 D.180x150x35,40 150-180-35.4 Viton/gommatela/pom 0.5
TDE 700600 D.177,80x152,40x32,15 152.4-177.8-32.15 Nbr/gommatela/pom 0.5
TDE 708629 D.180x160x031,40 160-180-31.4 Nbr/gommatela/pom 0.5
TDE/SP 708629 D.180x160x31,4 BRIT 160-180-31.4 Brit/gommatela/pom 0.5
TDE 748629 D.190x160x035,40 160-190-35.4 Nbr/gommatela/pom 0.5
D11W 748629 D.190x160x35,40 160-190-35.4 Nbr/gommatela/pom 0.5
TDE 787669 D.200x170x035,40 170-200-35.4 Nbr/gommatela/pom 0.5
VITON TDE 787669 D.200x170x35,40 170-200-35.4 Viton/gommatela/pom 0.5
D11W 787669 D.200x170x35,40 170-200-35.4 Nbr/gommatela/pom 0.5
D11W 800700 D.203,2x177,8x32,15 177-203-32.15 Nbr/gommatela/pom 0.5
TDE 826708 D.210x180x032,40 180-210-32.4 Nbr/gommatela/pom 0.5
TDE 866748 D.220x190x035,40 190-220-35.4 Nbr/gommatela/pom 0.5
D11W 866748 D.220x190x35,40 190-220-35.4 Nbr/gommatela/pom 0.5
VITON TDE 866748 D.220x190x35,40 190-220-35.4 Viton/gommatela/pom 0.5
TDE 984866 D.250x220x035,40 220-250-35.4 Nbr/gommatela/pom 0.5
D11W 984866 D.250x220x35,40 220-250-35.4 Nbr/gommatela/pom 0.5
TDE/SP 984866 D.250x220x35,4 BRIT 220-250-35.4 Brit/gommatela/pom 0.5
VITON TDE 984866 D.250x220x35,40 220-250-35.4 Viton/gommatela/pom 0.5
10D11W 11811062 D.300x270x35,40/6,35 270-300-35.4 Nbr/pom/tpe 0.5
D11W 11811062 D.300x270x35,40 270-300-35.4 Nbr/gommatela/pom 0.5
D11W 575475 D.146,05x120,65x32,15 120,65-146,05-32,15 Nbr/Gommatela/Pom 0,5
