MA47

|Working conditions: |Material: PTFE + CARBON |Pressure: = 350 bar |Speed: = 15 m/s |Temperature: -150°C + 250°C

Category: SEALS for Rotating shafts, Subcategory

Product Description

|Working conditions: |Material: PTFE + CARBON |Pressure: = 350 bar |Speed: = 15 m/s |Temperature: -150°C + 250°C

Additional information

Name Size Materials Speed Stock
MA 47 PTFE+CARB D012x017x3,60/0,85 12-17-3.6 Ptfe + carbone 15
MA 47 PTFE+CARB D012x017x3,60/0,85 silicone 12-17-3.6 Ptfe + carbone 15
MA 47 PTFE+CARB D015x20x3,6 15-20-3.6 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D020x025x36 20-25-3.6 Ptfe + carbone 15
MA 47 PTFE+CARB D024x033x3,60/0,85 24-33-3.6 Ptfe + carbone 15
DR117 PTFE/CARBON 24343239 D025x030/034x3,1/0,85 25-30-3.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D035x042x4,8 35-42-4.8 Ptfe + carbone 15
REH055 40-103-A-10 PTFE/CARB D040x047x4,8 40-47-4.8 Ptfe + carbone 15
REN055- 40,0-103-A-15 D040x050,5x7,1 40-50.5-7.1 Ptfe + carbone 15
REN055- 42,0-103-A-15 D042x052,5/59,5x7,1 42-52.5-7.1 Ptfe + carbone 15
MA 47 PTFE+CARB D045x055,5/62,5x7,1/1,8 45-55.5-7.1 Ptfe + carbone 15
MA 47 PTFE C CARB D048x070x9,5/2,8 48-70-9.5 Ptfe + carbone 15
REN055- 50,0-032-A-15 D050x060,5x7,1 50-60.5-7.1 Ptfe + carbone 15
MA 47 PTFE/CARB D060x070,5x7,1 60-70.5-7.1 Ptfe + carbone 15
REN055- 64,0-032-A-15 D064x074,5/081,5x7,1/1,8 64-74.5-7.1 Ptfe + carbone 15
REN055- 64,0-103-A-15 D064x074,5/81,5x7,1/1,8 64-74.5-7.1 Ptfe + carbone 15
REN055- 70-103-A-15 D070x080,5/087,5x7,1 70-80.5-7.1 Ptfe + carbone 15
REL055- 73,0-032-A-10 D073x078/082x3,60/0,85 73-78-3.6 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D075x085,5x7,1 75-85.5-7.1 Ptfe + carbone 15
MA 47 PTFE BEIGE + SIL D075x085,5x7,1 75-85.5-7.1 Ptfe + carbone 15
TVM300750-T40SM D075x085,5x7,1 75-85.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D078x088,5x7,1 78-88.5-7.1 Ptfe + carbone 15
REN055-80-103-A-15 - D080x090,5x7,1 80-90.5-7.1 Ptfe + carbone 15
REN055- 85,0-032-A-15 D085x095,5/102,5x7,1/1,8 85-95.5-7.1 Ptfe + carbone 15
REN055- 85,0-103-A-15 D085x095,5x7,1 85-95.5-7.1 Ptfe + carbone 15
REM055- 85,0-032-A-20-Q D085x099/107x9,5/2,8 85-99-9.5 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D090x100,5x7,1 90-100.5-7.1 Ptfe + carbone 15
TVM300900-T40SM D090x100,5x7,1 90-100.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D092x102,5x7,1 92-102.5-7.1 Ptfe + carbone 15
MA 47 PTFE C CARB D100x110,5x117,5x7,1 100-110.5-7.1 Ptfe + carbone 15
MA 47 PTFE+FIBRA DI CARBONIO D105x115,5x7,1 105-115.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D110x120,5x7,1 110-120.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D115x125,5x7,1 115-125.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D120x130,5x7,1 120-130.5-7.1 Ptfe + carbone 15
REN055-120,0-103-H-15 D120x130,5x7,1 120-130.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D130x140,5x7,1 130-140.5-7.1 Ptfe + carbone 15
MA 47 PTFE CARIC CARB D140x150,5x7,1 140-150.5-7.1 Ptfe + carbone 15
REN055-160,0-032-A-15 D160x170,5x7,1 160-170.5-7.1 Ptfe + carbone 15
MA 47 PTFE C CARB D180x190,5/197,5x7,1 180-190.5-7.1 Ptfe + carbone 15
MA 47 PTFE C CARB D200x210,5/217,5x7,1 200-210.5-7.1 Ptfe + carbone 15
MA 47 PTFE C CARB D240x250,5/257,5x7,1 240-250.5-7.1 Ptfe + carbone 15
