DIP

|Description: |Material: NBR. |Temperature: - 20°C + 100°C |Pressure: = 16 bar |Speed: = 1 m/s |Material: PU. |Temperature: - 30°C + 100°C |Pressure: = 16 bar |Speed: = 1 m/s |Material: VITON. |Temperature: - 20°C + 200°C |Pressure: = 16 bar |Speed: = 1 m/s

Category: PNEUMATIC Rod Seals, Subcategory

Product Description

|Description: |Material: NBR. |Temperature: - 20°C + 100°C |Pressure: = 16 bar |Speed: = 1 m/s |Material: PU. |Temperature: - 30°C + 100°C |Pressure: = 16 bar |Speed: = 1 m/s |Material: VITON. |Temperature: - 20°C + 200°C |Pressure: = 16 bar |Speed: = 1 m/s

Additional information

Name Size Materials Speed Stock
K53-008 D.008x011,6x2,8 8-11.6-2.8 Nbr 1
DIP 8-1 49066296 D.008x011,6x3,3 8-11.6-3.3 Nbr 1
K53-009 D.009x014x4,1 9-14-4.1 Nbr 1
K53-009,5 D.009,5x015x3,7 9.5-15-3.7 Nbr 1
DIP 9,5-1 12014783 D.009,5x015x4,5 9.5-15-4.5 Nbr 1
K53 NBR 012 D.012x018x4,1/5 12-18-4.1 Nbr 1
K53-PU-012 D.012x018x4,1/5 DIP 12-18-4.1 Pu 1
DIP 12-2 12018784 D.012x018x4,8 12-18-4.8 Nbr 1
K53-PU-012/1 D.012x020x6,2/7,8 12-20-6.2 Pu 1
K53-PU-014 D.014x022x6,2/7,8 14-22-6.2 Pu 1
VIT DIP 14-1 12012392 D.014x021,5x6,5/7,8 14-22-6.3 Viton 1
DIP 14-1 406509 D.014x022x7 14-22-7 Nbr 1
DIP 14-2 D.014x020x7 AMM-POLIURETANO 14-20-7 Pu 1
K53 NBR 014 D.014x022x7/7,8 14-22-7 Nbr 1
K53-PU-016/1 D.016x022x4,7/5,5 16-22-4.7 Pu 1
K53 NBR 016 D.016x024x6,2/7,8 16-24-6.2 Nbr 1
K53-PU-016 D.016x024x6,2/7,8 16-24-6.2 Pu 1
DIP 16-1 408706 D.016x024x6,5/7 16-24-6.5 Nbr 1
K53-016-VITON D.016x024x7,8 16-24-7.8 Viton 1
K53-PU-020 D.020x028x6,2/7,8 20-28-6.2 Pu 1
VIT DIP 20-1 12013038 D.020x027,5x6,5/7,8 20-27.5-6.3 Viton 1
DIP 20-1 408714 D.020x028x7 20-28-7 Nbr 1
K53-NBR-022 D.022x030x6,2/7,8 22-30-6.2 Nbr 1
DIP 22-1 408747 D.022x030x7/8 22-30-7 Nbr 1
VIT DIP 22-1 12012117 D.022x029,5x6,5/8 22-30-7 Viton 1
K53-022-VITON D.022x030x7,8 22-30-7.8 Viton 1
K53-PU-024 D.024x032x6,2/7,8 24-32-6.2 Pu 1
K53-PU-025/1 D.025x035x6,2/7,8 25-35-6.2 Pu 1
K53 NBR 025 D.025x033x6,3/7,8 25-33-6.3 Nbr 1
K53-PU-025 D.025x033x6,3/7,8 25-33-6.3 Pu 1
VIT DIP 25-1 12012119 D.025x032,5x6,5/7,8 25-33-6.3 Viton 1
K53-025-VITON D.025x033x7,8 25-33-7.8 Viton 1
DIP 25-1 408750 D.025x033x6,5/8 25-33-65 Nbr 1
K53-PU-028 D.028x036x6,2/7,8 28-36-6.2 Pu 1
K53-028-VITON D.028x036x6,2/7,8 28-36-6.2 Viton 1
DIP 28-1 408753 D.028x036x6,5/8 28-36-6.5 Nbr 1
K53-PU-030 D.030x040x6,2/7,8 30-40-6.2 Pu 1
DIP 30-1 408756 D.030x040,0x6,5/8 30-40-6.5 Nbr 1
K53-NBR-030 D.030x040x7/7,8 30-40-7 Nbr 1
VIT DIP 30-1 438249 D.030x040x8 30-40-8 Viton 1
K53-PU-032 D.032x040x6,2/7,8 32-40-6.2 Pu 1
K53-032/1-VITON D.032x042x7,8 32-42-7.8 Viton 1
DIP 34-1 12014754 D.034x043,0x6,5/8 34-43-6.5 Nbr 1
K53-PU-036 D.036x046x6,2/7,8 36-46-6.2 Pu 1
DIP 36 12013294 D.036x045,5x6,5/8 36-45.5-6.5 Nbr 1
K53-PU-040 D.040x050x6,2/7,8 40-50-6.2 Pu 1
VIT DIP 40-1 12012682 D.040x050x6,5/8 40-50-6.2 Viton 1
DIP 40-1 408759 D.040x050,0x7/8 40-50-7 Nbr 1
K53-NBR-040 D.040x050x7/7,8 40-50-7 Nbr 1
K53-040-VITON D.040x050x7,8 40-50-7.8 Viton 1
K53-PU-050/1 D.050x060x6,2/7,8 50-60-6.2 Pu 1
DIP 50-1 408761 D.050x060x6,5/8 50-60-6.5 Nbr 1
VIT DIP 50-1 12013078 D.050x059,5x6,5/8 50-59.5-6.5 Viton 1
K53-050-VITON D.050x067x11/11 50-67-11 Viton 1
K53-PU-050 D.050x067x11/12,5 50-67-11 Pu 1
K53-PU-057 D.057x074x10/11 57-74-10 Pu 1
K53-PU-070 D.070x087x10/11 70-87-10 Pu 1
